รายละเอียดสินค้า:
การชำระเงิน:
|
| ชื่อสินค้า: | รอกไฟฟ้า 20T พร้อมรอก | ความสามารถในการยก: | 20ต |
|---|---|---|---|
| ความสูงในการยก: | 9-42ม | ความเร็วในการยก: | การควบคุมนักประดิษฐ์ |
| ความเร็วในการทำงาน: | 5-20ม./นาที | ไอเอสโอ: | M5 |
| พิมพ์: | คานเดี่ยวหรือคานคู่ |
European electric hoist is a popular lifting equipment for material handling. it is compact and lightweight, suitable for use in factories,warehouses, etc. As an ideal hoisting mechanism, it often matches with overhead cranes and gantry cranes. it needs the main beam to support the entire electric hoist and moves along the track. its electric motor provides power source for lifting tasks. Beside these parts, European hoist also has reducer, drum set, hook and electrical control system. There producer reduces the speed of the motor and increases the torque so European hoist could meet the needs of lifting heavy objects.
| ITEM | VALUE |
| Applicable Industries | Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction works , Energy & Mining |
| After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
| Place of Origin | China |
| Power Source | Electric |
| Sling Type | Wire Rope/chain/winch/european |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 1 Year |
| Core Components | Motor, Bearing, Gear, Gearbox |
| Load(t) | Class | Lifting height (m) | Lifting speed (m/s) | Rope Reeving | Traveling speed (m/s) | Wheel load | weight (kg) |
| 1.6 | M6 | 6, 9, 12 | 1.6/10 | 2/1 | 2~20 | 6.1, 6.2, 6.3 | 300, 335, 370 |
| 2.5 | M6 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 9.1, 9.2, 9.3 | 315, 350, 385 |
| 3.2 | M5 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 11.5, 11.6, 11.7 | 335, 370, 405 |
| 6.3 | M5 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 22, 22.1, 22.2 | 400, 450, 500 |
| 8 | M6 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 28, 28.1, 28.2 | 580, 610, 640 |
| 10 | M5 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 34.7, 34.8, 34.9 | 580, 610, 640 |
| 10 | M6 | 6, 9, 12 | 0.66/4.0 | 4/1 | 2~20 | 34.7, 34.8, 34.9 | 650, 690, 730 |
| 12.5 | M5 | 6, 9, 12 | 0.66/4.0 | 4/1 | 2~20 | 43.3, 43.4, 43.5 | 660, 700, 740 |
| 3.2 | M5 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 11.9 | 510, 525, 540 |
| 6.3 | M5 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 20.9 | 632, 652, 672 |
| 10 | M5 | 6, 9, 12 | 0.8/5.0 | 4/1 | 2~20 | 30.0 | 871, 896, 921 |
| 12.5 | M5 | 6, 9, 12 | 0.66/4.0 | 4/1 | 2~20 | 40.5 | 890, 915, 940 |
| 16 | M5 | 6, 9, 12 | 0.66/4.0 | 4/1 | 2~20 | 59.4, 59.7, 60.0 | 1314, 1348, 1381 |
| 20 | M5 | 6, 9, 12 | 0.5/3.4 | 4/1 | 2~20 | 59.5 | 1718, 1766, 1814 |
| 32 | M5 | 6, 9, 12 | 0.8/3.3 | 6/1 | 2~20 | 95, 104 | 2826, 2920, 3091, 3199 |
Q1. What types of cranes do you offer?
A1:as a manufacturer with over 15 years' experience, rui cheng provide a range of cranes,in cluding gantry cranes, overhead cranes, electric hoist, ib cranes, and customized lifting solutions tailoredto specific industry needs, such as for steel, precast concrete, and container handling
Q2. How do l know which crane is suitable for my project?
A2: Our team of experts is here to help! By understanding your lifting capacity requirements,operational environment, and usage freguency, we can recommend the ideal crane solution for your project.Contact us for a free consultation.
Q3. How to choose the right crane?
A3: The following factors need to be considered when choosing a crane: Load capacity, Lifting height Working environment, Frequency of operation.
Q4. What maintenance services do you offer?
A4: We offer comprehensive maintenance plans, including preventive maintenance,inspection, repairand spare parts replacement, to keep your crane running efficiently and safely. Our service teamis available forscheduled and emergency support.
Q5: Can you accept OEM?
A5: Yes, of course. Any logo is acceptable.Material, Color, Size, Packing, Brand, Delivery etc,
Q6:What are your delivery and installation timelines?
A6: Delivery and installation timelines vary based on the type and customization of the crane Generally, standard cranes can be delivered within 6-8 weeks, while customized solutions mayreauire additional time, We aim to provide accurate timelines upfront to ensure smooth proiec tplanning.
Q7: Do you offer installation services?
A7: Yes, we provide comprehensive training programs for crane operators, including safety trainingmaintenance guidelines, and operational best practices to ensure your team is fully prepared tooperate the crane safely and efficiently.
